Bluetooth|Wi-Fi 802.11a/b/g/n/ac|1 x 10/100/1000 Mbit/s|
- Intel® I218V
- Wi-Fi 802.11a/b/g/n/ac
- Obsługa dual band 2.4/5 GHz
- Obsługa ASUS Wi-Fi Go! Utility
Ogólne | |
Wymiary | 30.5 cm x 24.4 cm |
Pozostałe | |
Akcesoria w zestawie |
- Instrukcja użytkownika - ASUS Q-Shield - 4 x kabel SATA 6Gb/s - 1 x antena ASUS 2T2R dual band Wi-Fi (Wi-Fi 802.11a/b/g/n/ac) - 1 x mostek SLI - 1 x Q-connector (2 w 1) |
Funkcje specjalne |
5-Way Optimization by Dual Intelligent Processors 5 ASUS 5X Protection - ASUS DIGI+ VRM - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - ASUS High-Quality 5K-Hour Solid Capacitors - ASUS Stainless Steel Back I/O ASUS TPU - Auto Tuning - GPU Boost - TPU switch ASUS EPU - EPU - EPU switch ASUS Digital Power Design - Industry leading Digital 12 Phase Power Design - Industry leading Digital 2 Phase DRAM Power Design - CPU Power Utility - DRAM Power Utility ASUS Wi-Fi GO! - Wi-Fi GO! Function: Cloud GO!, Remote Desktop, Remote Keyboard & Mouse, File Transfer - Wi-Fi GO! & NFC Remote app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems ASUS Exclusive Features - AI Suite 3 - Ai Charger+ - USB Charger+ - Anti-Surge - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - USB 3.0 Boost - Disk Unlocker - Turbo LAN - Crystal Sound 2 ASUS Quiet Thermal Solution - Stylish Fanless Design Heat-sink solution ASUS EZ DIY - Precision Tweaker 2 - ASUS O.C. Tuner - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS USB BIOS Flashback - ASUS UEFI BIOS EZ Mode - Push Notice ASUS Q-Design - ASUS Q-Shield - ASUS Q-Code - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector Special Memory O.C. Design Overclocking Protection - ASUS C.P.R.(CPU Parameter Recall) Media Streamer Turbo App Fan Xpert 3 |
Złącza zewnętrzne | 1 x PS/2 Klawiatura/Mysz Combo, 1 x MIC, 1 x RJ-45, 1 x Głośnik tylny, 1 x Line In, 1 x Line Out, 1 x Głośnik centralny / Subwoofer, 1 x D-Sub, 1 x DisplayPort, 1 x DVI-D, 1 x HDMI, 1 x S/PDIF, 2 x USB 2.0, 4 x USB 3.0 Rozwiń |
Obsługiwane systemy operacyjne | Windows 8, Windows 7 |
Szczegółowe dane o interfejsach dysków/napędów | Intel® Z97 chipset: - 1 x SATA Express, kompatybilny z 2 x SATA 6.0 Gb/s - 1 x M.2 Socket 3, , M Key, obsługa urządzeń typu 2260/2280 (SATA & PCIE) - 4 x SATA 6Gb/s, szare - Obsługa Raid 0, 1, 5, 1 - Obsługa Intel® Smart Response Technology, Intel® Rapid Start Technology, Intel® Smart Connect Technology ASMedia® PCIe SATA controller: - 2 x SATA 6Gb/s port(s), czarne Rozwiń |
Złącza PCI-E 16x ver. 3.0 | 2 |
Porty USB na tylnym panelu | 6 |
Złącza PCI-E 1x | 4 |
Złącza dostępne na płycie | 1 x Przełącznik EZ XMP, 1 x Zworka Clear CMOS, 1 x System panel, 1 x Przedni panel audio, 1 x Wyjście S/PDIF, 1 x 24pin ATX zasilanie, 1 x M.2, 1 x SATA Express, 6 x SATA III 6Gb/s, 2 x USB 2.0/1.1, 2 x USB 3.0, 1 x Thunderbolt, 1 x TPM, 1 x 4pin wentylator procesora, 1 x 4pin wentylator opcjonalny procesora, 1 x Przycisk zasilania, 1 x Przycisk USB BIOS Flashback, 1 x DRCT, 1 x Przycisk MemOK!, 1 x 8pin 12V zasilanie, 4 x 4pin wentylator obudowy, 1 x Przełącznik TPU, 1 x Przełącznik EPU Rozwiń |
Zintegrowany procesor | Nie |
Karta dźwiękowa | Realtek® ALC1150 8-Channel High Definition Audio CODEC featuring Crystal Sound 2 |
Zintegrowana karta graficzna | Obsługa APU |
Chipset | Intel® Z97 |
Bios |
- 64 Mb Flash ROM, - UEFI AMI BIOS, - PnP, - DMI2.7, - WfM2.0, - SM BIOS 2.8, - ACPI 5.0, - Multi-language BIOS, - ASUS EZ Flash 2, - CrashFree BIOS 3, - F11 EZ Tuning Wizard, - F6 Qfan Control, - F3 My Favorites, - Quick Note, - Last Modified log, - F12 PrintScreen, - F3 Shortcut functions, - ASUS DRAM SPD (Serial Presence Detect) Rozwiń |
Gniazdo PCI | Nie szt. |
Port / Złącze LPT | Nie |
Złącza PCI-E 4x | Nie |
Porty USB do wyprowadzenia z płyty | 8 |
Raid | Tak |
Złącze AGP | Nie |
Złącza PCI-E 8x | Nie |
Port / Złącze COM | Nie |
Maksymalna ilość urządzeń ATA | 0 |
Złącza PCI-E 16x ver. 2.0 | 1 |
Interfejs sieciowy | Bluetooth, Wi-Fi 802.11a/b/g/n/ac, 1 x 10/100/1000 Mbit/s, - Intel® I218V |
Liczba portów USB 3.0 | 8 |
Złącza mini-PCI-E 1x | Brak |
Maksymalna ilość urządzeń SATA | 6 |
Gniazdo procesora | LGA1150 |
Format płyty | ATX |
Liczba gniazd DDR3 | 4 |
Producent chipsetu | Intel |
Typ pamięci | DDR3 |
FireWire (IEEE 1394) | Nie |
Model | Z97-PRO(Wi-Fi ac) |
Oprogramowanie |
- Drivers - ASUS Utilities - EZ Update - Anti-virus software (OEM version) |
Maks. wielkość pamięci | 32 GB |
Rodzina procesora | Intel Core i7, Intel Core i3, Intel Core i5, Intel Celeron, Intel Pentium |
Częstotliwość szyny pamięci | 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 2400 MHz, 2600 MHz, 2200 MHz, 2133 MHz, 1866 MHz, 2000 MHz, 1600 MHz, 3100 MHz, 1333 MHz, 3200 MHz Rozwiń |
